| Product Name | Y-Strainer |  |
|---|---|---|
| Patt. No. | IYS01 | |
| Working Pressure | 16bar(DN50-400) 25bar(DN50-300) | |
| Working Temperature | -10°C~120°C | |
| Standards | BS7350-1990 | |
| Flange Types | EN1092-2 PN10/PN16/PN25 ANSI B16.1 Class 125,ANSI B16.2 Class 250 JIS10K/16K | |
| Face to Face | EN558 basic series 1 |
| Product Name | Y-Strainer | |
|---|---|---|
| Patt. No. | IYS01 | |
| Working Pressure | 16bar(DN50-400) 25bar(DN50-300) | |
| Working Temperature | -10°C~120°C | |
| Standards | BS7350-1990 | |
| Flange Types | EN1092-2 PN10/PN16/PN25 ANSI B16.1 Class 125,ANSI B16.2 Class 250 JIS10K/16K | |
| Face to Face | EN558 basic series 1 |
